ESD Magazine Rack Case

Customer Customized SMT ESD Magazine Rack Case

SMT PCB Magazine Rack Customer customization requirements

1, overall size :460*400*563mm;
2, starting size :A distance 34mm, B distance 34mm;
3, adjustment mode: belt adjustment mode, adjustable width 0-330mm;
4. The bottom plate is cut and bent with 1.2mm thick galvanized sheet, and the color of the leakage part is made black;
5. The groove plate is made of new PS material and fixed with rivets. The groove width is 5mm, the groove depth is 4mm, and the pitch is 10mm, with a total of 50 layers. As shown in Figure 2, the inlet and outlet of the slot plate are riveted，1.2mm thick 304 stainless steel plate to prevent the slot plate from opening, as shown in Figure 3, the stainless steel plate and the slot plate are bent: the inside of the slot plate shall not have the outside riveted rivet sticking out.
6. The column is made of solid reinforced aluminum profiles, and the column and bottom plate are locked and fixed with M6 locking screws and threaded glue;
7. The four corners of the bottom plate are fixed with 201 stainless steel of 105*100*2mm:
8, the fixed side is configured with two pressure spring L-type baffle pieces:
9, no marked tolerance of 0.5mm;
10. See the explosion diagram for the unmarked part of the material.
11, belt adjustment handle material: metal, according to the last sample to provide the material, but the size of the metal handle is not appropriate, finally provided drawings to (very important), must pay attention to

During the process of customizing the ESD Magazine Rack, we constantly negotiated with the customers regarding different design drawings and communicated with them about the details. Finally, we completed the rack product according to the customers' requirements.

The problems encountered by the customer during the installation of the material SMT ESD Magazine Rack

1.Lack of clear installation instructions: Some customers have reported being unsure about how to install the shelves correctly, especially for those who are new to it.

2.The installation process is complex: Although the manufacturers usually provide installation instructions, some customers still complain that the installation steps are not intuitive, especially when it comes to width adjustment or alignment of the anti-static rails

We have provided clear and concise video tutorials on SMT ESD Magazine Rack installation. If you encounter similar issues, you can watch our videos to solve them，

At the same time, we offer high-quality customized services. We have 15 years of experience in designing anti-static products.At the same time, we offer high-quality customized services. We have 15 years of experience in ESD industrial field.We offer excellent after-sales service. If you encounter any problems during the installation process, please feel free to contact us. We will provide you with high-quality technical support and remote guidance.
